Ammonia Separator
Ammonia Separator
- SMARTCOLD
- DALIAN, CHINA
- 45 DAYS
- 1 SET PER WEEK
Ammonia Separator Volume: 0.08-7.6 m3
Ammonia Separator Features
* To separator liquid ammonia from gas sourced from evaporator, and to avoid liquid hamper caused by liquid ammonia entering into compressor. Meanwhile, improve evaporator effective heat transfer area.
* Design Temp: 43℃ * Design Pressure: 1.6 Mpa
* Hydraulic Test: 2.0 MPa * Air Tight Test: 1.6 Mpa
Ammonia separator technology parameter
型号 Model | 容积 Volume | 设备尺寸 Dimension | 重量 Weight | |
筒体直径 Cylinder Dia. | 高度 Height | |||
m3 | mm | mm | kg | |
AF-65 | 0.08 | φ325 | 1428 | 111 |
AF-80 | 0.17 | φ426 | 1630 | 172 |
AF-100 | 0.3 | φ516 | 1814 | 212 |
AF-125 | 0.5 | φ616 | 2114 | 347 |
AF-150 | 1.1 | φ816 | 2541 | 542 |
AF-150A | 1.7 | φ1016 | 2611 | 706 |
AF-200 | 1.7 | φ1016 | 2611 | 750 |
AF-200A | 2.6 | φ1220 | 2713 | 1051 |
AF-250 | 3.1 | φ1220 | 3213 | 1290 |
AF-250A | 4.4 | φ1420 | 3313 | 1520 |
AF-300 | 4.4 | φ1420 | 3313 | 1605 |
AF-300A | 7.6 | φ1828 | 3517 | 2724 |
型号 Model | 容积 Volume | 设备尺寸 Dimension | 重量 Weight | ||
筒体直径 Cylinder Dia. | 长度 Length | 高度 Height | |||
m3 | mm | mm | mm | kg | |
WAF-80 | 1.1 | φ816 | 2322 | 1334 | 649 |
WAF-100 | 2.1 | φ1016 | 2922 | 1538 | 913 |
WAF-125 | 3.2 | φ1220 | 3023 | 1738 | 1318 |
WAF-150 | 5.2 | φ1420 | 3623 | 1942 | 1780 |
WAF-200 | 6.9 | φ1624 | 3727 | 2146 | 2530 |
