Inter Cooler
Inter Cooler
- SMARTCOLD
- DALIAN, CHINA
- 45 DAYS
- 1 SET PER WEEK
Inter Cooler Heat Exchange Area: 2-35 m3
Inter Cooler
* The unit is applied in dual-stage or multi-stage compressor unit system. It is used to cool over-heat gas exhausted from low pressure stage or low pressure compressor, as well as over-cooling high pressure ammonia liquid to improve refrigeration capacity.
*Design Temp: Inside Cylinder 43℃ , Inside Coil 50℃
*Design Pressure: Inside Cylinder 1.6MPa, Inside Coil2.1MPa
*Hydraulic Test: Inside Cylinder 2.0MPa, Inside Coil 2.63MPa
*Air Tight Test: Inside Cylinder 1.6MPa, Inside Coil 2.1 MPa
Inter Cooler data
| 型号 Model | 换热面积 Heat Exchange Area | 设备尺寸 Dimension | 重量 Weight | |
| 筒体直径 Cylinder Dia. | 高度 Height | |||
| m2 | mm | mm | kg | |
| ZL-2.0 | 2 | φ516 | 2814 | 417 |
| ZL-3.5 | 3.5 | φ616 | 2864 | 530 |
| ZL-5.0 | 5 | φ816 | 3264 | 831 |
| ZL-8.0 | 8 | φ1016 | 3264 | 1203 |
| ZL-10 | 10 | φ1220 | 3613 | 1815 |
| ZL-16 | 16 | φ1220 | 3613 | 1953 |
| ZL-20 | 20 | φ1624 | 3869 | 2805 |
| ZL-25 | 25 | φ1624 | 3869 | 2921 |
| ZL-30 | 30 | φ1624 | 4069 | 3139 |
| ZL-35 | 35 | φ1824 | 3957 | 3792 |
