Oil Collector
Oil Collector
- SMARTCOLD
- DALIAN, CHINA
- 45 DAYS
- 1 SET PER WEEK
Oil Collector Volume: 0.025-0.26 m3
Oil Collector Features.
* Oil collector is used to collect lubrication oil from ammonia separator and other accessories and drain oil in low pressure condition to reduce ammonia loss as well as ensuring operators security.
* Design Pressure: 2.1Mpa
* Hydraulic Test: 2.1 Mpa
Oil Collector Table
| 型号 Model | 设计温度 Design Temp | 液压试验压力 Hydraulic Test | 容积 Volume | 设备尺寸 Outline | 重量 Weight | |
| 圆筒直径 Cylinder Dia. | 高度 Height | |||||
| ℃ | MPa | m3 | mm | mm | kg | |
| JY-200 | 50 | 2.63 | 0.025 | φ219 | 921 | 60 |
| JY-300 | 50 | 2.63 | 0.075 | φ325 | 1178 | 103 |
| JY-500 | 50 | 2.63 | 0.26 | φ516 | 1581 | 215 |
| RJY-500 | 100 | 2.65 | 0.26 | φ516 | 1581 | 196 |
How To Order ?
Step 1, please tell us what model and quantity you need; Step 2, then we will make a Pl for you to confirm the order details; step 3, when we confirmed everything, can arrange the payment; step 4, finally we deliver the goods within the stipulated time....more
Step 1, please tell us what model and quantity you need; Step 2, then we will make a Pl for you to confirm the order details; step 3, when we confirmed everything, can arrange the payment; step 4, finally we deliver the goods within the stipulated time....more
