Freon Industrial Air Cooler

Freon Industrial Air Cooler

Brand SMARTCOLD
Product origin DALIAN, CHINA
Delivery time 45 DAYS
Supply capacity 1 SET PER WEEK

Freon Industrial Air Cooler Widely used in refrigeration or a variety of high and low temperature cold storage, etc.

Email

Freon Industrial Air Cooler Features

*Refrigerant: Freon R22、R404A、R507A, etc.

*Heat transfer tubes: 20 diameter steel or stainless steel tube;

Fin: steel or aluminum,

Fin spacing: 8mm, 10mm, and 12mm

*Shell: galvanized steel plate, stainless steel plate and aplastic steel

*Defrost forms: air defrosting, electric defrosting

*Maintenance-free axial fan with low noise, motor protection IP54

*Suspension finned coil structure, safe and reliable structure, high strength of structure

*Corrugated fins, overall galvanized or tube expanding process to make the fin coil close, high heat transfer efficiency, long service life

*Optimized defrost design, improve the defrosting efficiency, prevent splash phenomenon

*Provide a variety of combinations, free for the user to choose

Freon Industrial Air Cooler

Freon Industrial Air Cooler Table

Model	Refrigeration Capacity		Evap. Area	Air volume	Expected range	Input power rating	Refrigerant		Electric defrosting Power
	Refrigeration Capacity						Refrigerant
	t = 0℃ t₀= -8℃	t = -18℃ t₀= -25℃					Inlet	Outlet
	t = 0℃ t₀= -8℃	t = -18℃ t₀= -25℃					Inlet	Outlet
	kW	kW	m²	m³/h	m	kW	mm	mm	kW
ZLF18C71E	9.86	7.74	73.13	11000	26	0.94	DN25	DN40	8.78
ZLF18C91E	17.26	13.54	127.97	19500	30	1.85	DN25	DN40	15.36
ZLF110C71E	8.05	6.32	59.71	11500	26	0.94	DN25	DN40	7.16
ZLF110E71E	13.42	10.53	99.51	10500	25	0.94	DN25	DN40	11.94
ZLF110E91E	23.49	18.43	174.15	18500	30	1.85	DN25	DN40	20.9
ZLF112D71E	9.13	7.16	67.68	11500	26	0.94	DN25	DN40	9.48
ZLF112E71E	11.41	8.95	84.6	10500	25	0.94	DN25	DN40	11.84
ZLF112F71E	13.69	10.74	101.52	10000	24	0.94	DN25	DN40	14.21
ZLF112C91E	11.98	9.4	88.83	21500	31	1.85	DN25	DN40	12.44
ZLF112D91E	15.98	12.53	118.44	20500	30	1.85	DN25	DN40	16.58
ZLF112F91E	23.96	18.8	177.66	19000	28	1.85	DN25	DN40	24.87
ZLF28C71E	20.12	15.78	149.18	22000	26	2x0.94	DN25	DN40	17.9
ZLF28C91E	35.02	27.47	259.6	39000	30	2x1.85	DN40	DN65	31.15
ZLF210C71E	16.43	12.89	121.8	23000	26	2x0.94	DN25	DN40	14.62
ZLF210E71E	27.38	21.48	203	21000	25	2x0.94	DN25	DN40	24.36
ZLF210E91E	47.65	37.38	353.27	37000	30	2x1.85	DN40	DN65	42.39
ZLF212D71E	18.62	14.61	138.07	23000	26	2x0.94	DN25	DN40	19.33
ZLF212E71E	23.28	18.26	172.59	21000	25	2x0.94	DN25	DN40	24.16
ZLF212F71E	27.94	21.91	207.11	20000	24	2x0.94	DN25	DN40	28.99
ZLF212C91E	24.31	19.07	180.2	43000	31	2x1.85	DN40	DN65	25.23
ZLF212D91E	32.41	25.42	240.27	41000	30	2x1.85	DN40	DN65	33.64
ZLF212F91E	48.61	38.14	360.4	38000	28	2x1.82	DN40	DN65	50.46
ZLF38C71E	30.38	23.83	225.23	33000	26	3x0.94	DN40	DN65	27.03
ZLF38C91E	52.77	41.4	391.22	58500	30	3x1.85	DN50	DN80	46.95
ZLF310C71E	24.8	19.46	183.9	34500	26	3x0.94	DN40	DN65	22.07
ZLF310E71E	41.34	32.43	306.5	31500	25	3x0.94	DN40	DN65	36.78
ZLF310E91E	71.81	56.33	532.39	55500	30	3x1.85	DN50	DN80	63.89
ZLF312D71E	28.12	22.06	208.46	34500	26	3x0.94	DN40	DN65	29.18
ZLF312E71E	35.15	27.57	260.57	31500	25	3x0.94	DN40	DN65	36.48
ZLF312F71E	42.18	33.09	312.69	30000	24	3x0.94	DN40	DN65	43.78
ZLF312C91E	36.63	28.74	271.57	64500	31	3x1.85	DN50	DN80	38.02
ZLF312D91E	48.84	38.31	362.1	61500	30	3x1.85	DN50	DN80	50.69
ZLF312F91E	73.26	57.47	543.15	57000	28	3x1.82	DN50	DN80	76.04

FAQ

How To Order ?
Step 1, please tell us what model and quantity you need; Step 2, then we will make a Pl for you to confirm the order details; step 3, when we confirmed everything, can arrange the payment; step 4, finally we deliver the goods within the stipulated time....more
