Industrial Quick Freezer Air Cooler

Brand SMARTCOLD
Product origin DALIAN, CHINA
Delivery time 45 DAYS
Supply capacity 1 SET PER WEEK

Industrial Quick Freezer Air Cooler Widely used in all kinds of frozen room etc

Email

Industrial Quick Freezer Air Cooler Features

*Refrigerant: Freon R22、R404A、R507A, etc.

*Heat transfer tubes: 20 diameter steel or stainless steel tube;

Fin: steel or aluminum,

Fin spacing: 8mm, 10mm, and 12mm

*Shell: galvanized steel plate, stainless steel plate and aplastic steel

*Defrost forms: air defrosting, electric defrosting

*Maintenance-free axial fan with low noise, motor protection IP54

*Suspension finned coil structure, safe and reliable structure, high strength of structure

*Corrugated fins, overall galvanized or tube expanding process to make the fin coil close, high heat transfer efficiency, long service life

*Optimized defrost design, improve the defrosting efficiency, prevent splash phenomenon

*Provide a variety of combinations, free for the user to choose

Industrial Quick Freezer Air Cooler

Industrial Quick Freezer Air Cooler Table

Model	Refrigeration Capacity	Evap. Area	Air volume	Expected range	Input power rating	Refrigerant		Amount of deforsting water (W)	Air duct heating power (H)	Net weight
	t = -34℃ t₀= -40℃					Inlet	Outlet			Water deforsting (SS) (SA)	Hot Ammonia deforsting (SS) (SA)
	kW	m²	m³/h	m	kW	mm	mm	t/h	kW	kg	kg
(D/L)(A/F)214D80W-SS20Z	13.19	210	42000	30	2x3.0	DN40	DN65	10.5	2x0.35	910	965
										1110	1190
(D/L)(A/F)214E80W-SS20Z	16.48	262.53	42000	30	2x3.0	DN40	DN65	13.13	2x0.35	960	1015
										1190	1245
(D/L)(A/F)214F80W-SS20Z	19.78	315.04	42000	28	2x3.0	DN40	DN65	15.75	2x0.35	1010	1065
										1240	1295
(D/L)(A/F)21014F80W-SS20Z	24.34	387.63	42000	28	2x3.0	DN40	DN65	19.38	2x0.35	1040	1095
										1270	1325
(D/L)(A/F)314D80W-SS20Z	19.87	316.52	63000	30	2x3.0	DN50	DN80	15.83	3x0.35	1315	1475
										1705	1775
(D/L)(A/F)314E80W-SS20Z	24.84	395.64	63000	30	2x3.0	DN50	DN80	19.78	3x0.35	1385	1515
										1775	1820
(D/L)(A/F)314F80W-SS20Z	29.81	474.77	63000	28	2x3.0	DN50	DN80	23.74	3x0.35	1490	1570
										1830	1900
(D/L)(A/F)31014F80W-SS20Z	36.68	584.17	63000	28	2x3.0	DN50	DN80	29.21	3x0.35	1510	1590
										1850	1920
